UV-VIS-NIR-Spectrometer from OtO Photonics
UM1280-100-V2
The ultra compact cost effective spectrometers of the UM series cover the UV-VIS-NIR range from 330 – 850 nm. OtO uses a Si-MEMS design combined with a separate USB control board in order to set-up these smallest micro spectrometers.
Markets
Metrology
Electronic
Chemical & Pharma
Medical
Biophotonics
Photonics
Semiconductor
Print
Food
Science
Electronic
Chemical & Pharma
Medical
Biophotonics
Photonics
Semiconductor
Food
Science
Applikations
Optical characterization of light sources
Laser characterization
LED testing
Filter characterization
Display testing
Colorimetry
Fluorescence spectroscopy
Water analysis
Gas analysis
Differential optical absorption spectroscopy (DOAS)
Continuous Emission Monitoring Systems (CEMS)
Ellipsometry
Blood analysis
OCT
Colour analysis
Thin-film measurement
Reflection spectroscopy
Absorption spectroscopy
Emission spectroscopy
Concentration
Material identification
LIBS
Laser characterization
LED testing
Filter characterization
Display testing
Colorimetry
Fluorescence spectroscopy
Water analysis
Gas analysis
Differential optical absorption spectroscopy (DOAS)
Continuous Emission Monitoring Systems (CEMS)
Ellipsometry
Blood analysis
OCT
Colour analysis
Thin-film measurement
Reflection spectroscopy
Absorption spectroscopy
Emission spectroscopy
Concentration
Material identification
LIBS
Features
Rugged Si-MEMS technology
Good temperature stability
Sensitive CCD sensor
Easy connected via SMA fiber
Optional SpectraSmart readout and evaluation software
Optional SDK and libraries
Optional USB and UART interface
No moving parts
Good temperature stability
Sensitive CCD sensor
Easy connected via SMA fiber
Optional SpectraSmart readout and evaluation software
Optional SDK and libraries
Optional USB and UART interface
No moving parts
Benefits
Most compact size using concave gratings
Wide temperature range using Si-MEMS technology
Low weight
24/7 operation
Synchronization with light sources
Portable for mobile applications
Fast and easy operation with opt. plug & play Windows software
Easy integration into the existing software environment (opt.)
Directly available: reflection / transmission / absorption / concentration (opt.)
Colorimeter data available (opt.)
Maintenance free
Wide temperature range using Si-MEMS technology
Low weight
24/7 operation
Synchronization with light sources
Portable for mobile applications
Fast and easy operation with opt. plug & play Windows software
Easy integration into the existing software environment (opt.)
Directly available: reflection / transmission / absorption / concentration (opt.)
Colorimeter data available (opt.)
Maintenance free
- Specifications
- Data Sheet
- Videos
- Additional Products
Additional information
| Manufacturer | OtO Photonics |
|---|---|
| Part Number | UM1280-100-V2 |
| Product | UV-VIS-NIR-Spectrometer |
| Wavelength min. in nm | 330 |
| Wavelength max. in nm | 850 |
| Resolution in nm | 20,0 |
| Slit Size in µm | 100 |
| Bandwidth in nm | 520 |
| Grating in g/mm | 300 |
| Choice Spectrometer Series | Micro-Spectrometer with Si-MEMS Technology (UM Serie) |
| Choice Detector | Ultra Micro 39.3 x 43.5 x 10.1 mm (SMA), Low Cost UM1280 |
| SNR | 150 |
| Stray Light in % | 1 |
